Description

Paper carton erecting machine is an ideal choice to produce hamburger boxes,chips boxes,take away box,etc.lt adopts micro-computer,PLC,servo feeding,alternating current frequency converter ,the vacuum-sucking,auto gluing, automatic paper tape counting,chain drive.All of these main parts and electric control system adopts famous brand to guarantee steady working,precise positioning,smooth running,safety and reliability operation.

Technology Specifications

Model	FBN-PC1400Por
Advantage	Upgraded Double-station 5 sets servo motor: - Paper feeding 2sets - Paper transporting 1set - Paper downward 1set - Carton forming 1set
Production Capacity	150-500pcs/min
Suitable Material	Weight 200-600gsm: Card paper，PE coated paper, Kraft paper, Corrugated paper Max.Thickness: 1.5mm
Paper unfold size	Length 100-500mm Width100-500mm Height 15-200mm Degree: 4°-40°
Total Power	9 KW
Weight	2.8T
Dimension（mm）	3400 x 1800 x 1600
Power source	3Phase 380V 50HZ (other voltage can be customized)

Machine Details

Paper Feeder

feeding paper by servo motor)

Suitable Material

Card paper,PE coated paper,

Kraft paper, Corrugated paper.

Weight: 200-600gsm: Max.Thickness: 1.5mm

Paper Transporting System

by servo motor

Glue Feeding System

machine including rolling type

Optional

-Hot melt glue machine

-cold glue sprayer

Paper Downward

by servo motor

Carton Forming

By servo motor

Extra Mould Price：220USD/SET

Collection Unit

2 collection units

Configuration List

Model	FBN-PC1400Por
Main Motor	KongDe - China
Servo Motor (paper feeding)	- China
Servo motor (paper transporting)	- China
Servo motor (paper downward )	- China
Servo motor (carton forming)	- China
Gluing motor	ZhanPeng - China
Motion controller	- China
HMI	- China
PLC	/
Frequency Converter	/
Relay	- France
Low Voltage Apparatus	- France
Button	- France
Magnetic Switch/Senor	- Japan
Power Switch	- Taiwan
Pneumatic (cylinder)	- Taiwan
Paper feeding belt	- Japan
Convey Belt	JIEBAO - China
Main Bearing	- Japan

Optional configuration

Glass Cover（Protection）

Protection

Hot melt glue machine

Carton Forming

Automatic cold glue sprayer

Carton Forming

Plasma system

Remove PE coating

Get A Touch

Tailored Design Matching

Production Line Upgrade

Full Expert Support

Length: 100-500mm	Width: 100-500mm
Height: 15-200mm	Degree: 4°~ 40°
